APV-35-36 Led driver, 36W, 36V, 1A CV, MEAN WELL
| Quantity | Unit price |
|---|---|
| To 49 |
€11.20*
|
| To 99 |
€11.01*
|
| From 100 |
€10.74*
|
Available, delivery time: 1-3 days
| Product number: | 102490 |
|---|---|
| Manufacturer number: | APV-35-36 |
| EAN | 4021087026598 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
MEAN WELL APV-35 Series Description:
The APV-35 Series LED Power Supplies from MEAN WELL are the perfect solution for your LED lighting needs. With a constant voltage design, these power supplies are fully insulated and offer protection against short circuits, overvoltage, and overload. They also feature a small and compact size, making them ideal for use in advertising signs or other LED lighting applications. In addition, the APV-35 Series is UL 8750 and EN 55032 compliant, ensuring that your product meets the highest safety and EMC standards.
MEAN WELL APV-35 Series Features:
- Constant voltage design
- Universal AC input
- Protection functions: short circuit / overvoltage / overload
- Fully insulated plastic housing
- Small and compact size
- Cooling by free air convection
- IP42 design
- Suitable for LED and lighting applications such as advertising signs
- Attractive price and high reliability
- Not dimmable
- Withstands 300V AC surge voltage for 5 seconds
- Safety standards: UL 8750
- EMC standards: EN 55032
Notice:
Power supply for the operation of LED light sources.
Please note:
This power supply is intended for installation in terminal equipment.
This product is not designed to operate in an idle state.
For installation only in equipment that has a primary use other than illumination, such as copiers, overhead and slide projectors, or for scales and display lighting. This product is not intended for lighting applications within the European Economic Area.
For detailed technical specifications, please check the data sheet in the "downloads" section.
| Series: | MEAN WELL APV Series |
|---|
Technical data
| Product number: | 102490 |
|---|---|
| Size: | 84mm x 57mm x 29.5mm |
| Protection: | Short circuit protection SCP, overcharge OPP, overvoltage OVP |
| Weight: | 0.18kg |
| Electrical Connection Type: | 150mm Cables |
| Number of Outputs: | 1 |
| Efficiency: | 85% |
| Sealing Class: | IP42 |
| Output Current: | 1A |
| Output Voltage: | 36V DC |
| Power: | 36W |
| Power Supply Characteristics: | Constant voltage |
| Application: | LED |
| Series: | APV-35 |
| Note: | Stromversorgung für den Betrieb von LED-Lichtquellen. Bitte beachten: Dieses Netzteil ist für den Einbau in Endgeräte bestimmt. Dieses Produkt ist nicht für den Betrieb im Leerlaufzustand ausgelegt. Nur für den Einbau in Geräten, die einen anderen Primärgebrauch aufweisen als die Beleuchtung, z. B. Kopiergeräte, Overhead- und Diaprojektoren, oder für Skalen und Anzeigebeleuchtung. Dieses Produkt ist für Beleuchtungsanwendungen innerhalb des europäischen Wirtschaftsraums nicht vorgesehen. |
| Size: | 84mm x 57mm x 29.5mm |
| Weight: | 0.18kg |
Downloads
| Data Sheet: | meanwell-apv-35-spec-data-sheet.pdf |
|---|
