BUELA 300 K rot / red
€1.13
Currently not available (delivery time on request)
| Product number: | 201682 |
|---|---|
| Manufacturer number: | 931667101 |
| EAN | 4250260224425 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
Product information "BUELA 300 K rot / red"
BUELA 300 K rot / red (931667101)
Multiple-spring wire plug, shatter-proof, flexible insulated sleeve with transverse hole. Lateral supports provide protection against contact when plugged in at right angles. The tapering sleeve end also serves as kinking protection for the lead. Solder connection up to maximum cable cross-section of 2.5 mm².
Technical data |
|
| connection | solder connection |
| rated voltage | 30 VAC / 60 VDC |
| measurement cat. acc. to IEC 61010 | O (2) |
| rated current (consider derating curve) |
30 A |
| material plug | brass, nickel plated |
| housing material | PVC-P |
| temperature range acc. To IEC61010(1) | -25 °C to +70 °C |
| Product number: | 201682 |
|---|
