HRP-100-15 Switching power supply, closed, 105W, PFC 15V, 7A, MEAN WELL
| Quantity | Unit price |
|---|---|
| To 49 |
€43.30*
|
| To 99 |
€42.57*
|
| From 100 |
€41.49*
|
Available, delivery time: 1-3 days
| Product number: | 100268 |
|---|---|
| Manufacturer number: | HRP-100-15 |
| EAN | 4021087017251 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
MEAN WELL HRP-100 Switching Power Supply Series Description:
The HRP-100 Series is a line of high-quality switching power supplies with an enclosed design and screw terminals. They feature universal input, overvoltage protection 300V AC/5s, and overload protection by current limiting with auto recovery. These power supplies are also protected against short circuits and feature a built-in PFC circuit.
MEAN WELL HRP-100 Switching Power Supply Series Features:
- enclosed design (case), screw terminals
- universal input
- Overvoltage protection 300V AC/5s
- overload protection by current limiting, auto recovery
- protected against short circuit, overload, overvoltage
- built-in PFC circuit
- low profile
- long life 105°C electrolytic capacitors
- low no-load power
- switching on and off of output voltage via remote signal
Notice:
This product is intended for installation in terminal equipment.
For detailed technical specifications, please check the data sheet in the "downloads" section.
Technical data
| Product number: | 100268 |
|---|---|
| Size: | 159mm x 97mm x 38mm |
| Protection: | Short circuit protection SCP, overcharge OPP, overvoltage OVP |
| Weight: | 0.56kg |
| Electrical Connection Type: | Terminal strip |
| Installation: | Mounting |
| Number of Outputs: | 1 |
| Efficiency: | 88% |
| Case type: | 901 |
| Output Current: | 7A |
| Output Voltage Range: | 14.25...18V DC |
| Output Voltage: | 15V DC |
| Power: | 105W |
| Power Supply Characteristics: | Module |
| Series: | HRP-100 |
| Note: | Dieses Produkt ist für den Einbau in Endgeräten bestimmt. |
| Size: | 159mm x 97mm x 38mm |
| Weight: | 0.56kg |
Downloads
| Data Sheet: | meanwell-hrp-100-spec-data-sheet.pdf |
|---|
