SPAN02A-12 DC/DC Converter 9-18V:+12V 167mA 2W, MEAN WELL
| Quantity | Unit price |
|---|---|
| To 49 |
€7.67*
|
| To 99 |
€7.42*
|
| From 100 |
€7.04*
|
Available, delivery time: 1-3 days
| Product number: | 103887 |
|---|---|
| Manufacturer number: | SPAN02A-12 |
| EAN | 4021087047012 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
Meanwell SPAN02 DC/DC Converter Series Features:
- SIP/SIL8 package
- for direct PCB mounting
- input voltage ratio: 2:1
- no minimum load required
- input/output isolation 1500V
- regulated output voltage
- according to EN55032 radiated class A without additional components
- efficiency up to 84%
- Remote control
For detailed technical specifications, please check the data sheet in the "downloads" section.
Technical data
| Product number: | 103887 |
|---|---|
| Size: | 21.8mm x 9.2mm x 11.1mm |
| Protection: | Short circuit protection SCP, overcharge OPP |
| Weight: | 0.0048kg |
| Installation: | Through Hole Technology / Durchsteckmontage (THT) |
| Number of Outputs: | 1 |
| Efficiency: | 83% |
| Output Current: | 0...167mA |
| Output Voltage: | 12V DC |
| Power: | 2W |
| Series: | SPAN02 |
| Size: | 21.8mm x 9.2mm x 11.1mm |
| Weight: | 44,777kg |
Downloads
| Data Sheet: | meanwell-span02dpan02-spec-data-sheet1.pdf |
|---|
