SPU03N-05 DC/DC Converter 24:5V 600mA 14W, MEAN WELL
| Quantity | Unit price |
|---|---|
| To 49 |
€5.71*
|
| To 99 |
€5.51*
|
| From 100 |
€5.24*
|
Currently not available (delivery time on request)
| Product number: | 103923 |
|---|---|
| Manufacturer number: | SPU03N-05 |
| EAN | 4021087000277 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
Meanwell SPU03 DC/DC Converter Series Features:
- in SIP/SIL7 housing
- for direct PCB mounting
- galvanic isolation of input and output
- input/output isolation 3000V
- unregulated
For detailed technical specifications, please check the data sheet in the "downloads" section.
Technical data
| Product number: | 103923 |
|---|---|
| Size: | 19.6mm x 7.5mm x 10.2mm |
| Protection: | Short circuit protection SCP, overcharge OPP |
| Weight: | 0.0029kg |
| Number of Outputs: | 1 |
| Efficiency: | 83% |
| Output Current: | 600mA |
| Output Voltage: | 5V DC |
| Power: | 3W |
| Series: | SPU03 |
| Size: | 19.6mm x 7.5mm x 10.2mm |
| Weight: | 44,806kg |
Downloads
| Data Sheet: | meanwell-spu03-spec-data-sheet.pdf |
|---|
