UNI-T UT8803E Bench Multimeter | True RMS, 3.8-Digit, 0.3% Accuracy, LAN
| Product number: | 202699 |
|---|---|
| Manufacturer number: | UT8803E |
| EAN | 6935750588116 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
Main Produkt-Features
- Precise True RMS Measurements: Delivers accurate readings even on complex, non-sinusoidal AC waveforms, such as those from switching power supplies or VFDs.
- High Resolution & Accuracy: With a 3.8-digit display (5,999 counts) and 0.3% DC voltage accuracy, you can reliably capture even the smallest signal changes.
- Comprehensive Measurement Functions: Measures DC/AC voltage, DC/AC current, resistance, capacitance, frequency, temperature, inductance, diode test, and continuity – one device for all your needs.
- Modern LAN Connectivity: Seamlessly integrate the multimeter into automated test systems, perform data logging, or control it remotely with ease.
- Intelligent Auto-Ranging: The device automatically selects the optimal measurement range, speeding up operation and minimizing errors.
- Visual Trend Analysis: The large display features an analog bar graph that shows signal stability and trends at a glance – an advantage a purely numeric display cannot offer.
- Certified Safety: The product is fully EU compliant and meets all relevant safety standards for worry-free use in professional environments.
UNI-T UT8803E: Precision and Versatility for Your Workbench
The Foundation for Reliable Measurements
In modern electronics development, quality assurance, and education, precision is not an option but a necessity. The UNI-T UT8803E Bench Multimeter is designed to meet this exact requirement. It combines a solid 0.3% accuracy for DC voltage measurements with a high resolution of 5,999 counts to give you a clear and dependable picture of your circuits. The generous and bright display ensures you can read all values effortlessly, even when the device is placed further away on the bench. Rely on a measuring device that is not only powerful but also completely safe and compliant with all relevant EU standards. This gives you the confidence to work in a safe and compliant environment.
Beyond the Basics: Expanded Measurement Capabilities
The UT8803E goes far beyond the basic functions of a standard multimeter. Its True RMS capability is essential for accurate measurements on modern electronic loads. Additionally, it offers special functions like inductance measurement for characterizing coils and transformers, and temperature measurement using a K-type thermocouple. These advanced capabilities make the UT8803E a true all-rounder, reducing the need for multiple individual devices and keeping your workspace clutter-free.
Seamless Integration into Your Workflow
The integrated LAN interface sets the UT8803E apart from simple bench multimeters. It allows for remote control of the device and automated acquisition of measurement data. Whether for long-term data logging to monitor system stability or for integration into a computer-aided test rack, the network connectivity opens up new possibilities for efficiency and documentation in your measurement processes.
Technical Specifications of the UT8803E
| Feature | Specification |
|---|---|
| Display | 3.8-digit, 5,999 counts |
| AC Measurement Principle | True RMS |
| DC Voltage Accuracy | ±0.3% |
| Measurement Functions | DC/AC Voltage, DC/AC Current, Resistance, Capacitance, Frequency, Temperature, Inductance, Diode Test, Continuity Test |
| Range Selection | Automatic (Auto-Ranging) |
| Connectivity | LAN Interface |
| Special Features | Analog Bar Graph, Data Hold, Max/Min Value Capture |
| Temperature Measurement | Via K-type thermocouple |
| Safety & Conformity | Meets EU standards |
Frequently Asked Questions (FAQ)
What does 'True RMS' mean?
True RMS (Root Mean Square) allows for precise measurements of AC voltages and currents, even when their waveform is not perfectly sinusoidal. This is often the case with modern electronic devices like switching power supplies or variable frequency drives.
Can I control the UT8803E remotely?
Yes, thanks to the integrated LAN interface, you can connect the multimeter to a computer to start measurements remotely, log data, and integrate the device into automated test procedures.
What applications is this bench multimeter best suited for?
The UT8803E is ideal for engineering teams in development, quality assurance in manufacturing, service and repair work, and for use in technical training labs.
Is the device certified for use in Europe?
Yes, the UT8803E is fully designed and tested for the European market. It meets all necessary EU norms and safety standards, ensuring safe operation.
| Product number: | 202699 |
|---|
| Flyer: | ut8803e-datenblatt-datasheet.pdf |
|---|---|
| Manual: | ut8803e-anleitung-deutsch.pdf |
| Other documents: | ut8803e-user-manual-english.pdf |
