UNI-T UTD2052CL+ Digital Storage Oscilloscope | 50 MHz, 2 Channels, 500 MSa/s
| Product number: | 202698 |
|---|---|
| Manufacturer number: | UTD2052CL+ |
| EAN | 6935750591284 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
Main Product-Features
- 50 MHz Bandwidth for precise measurements in basic electronics applications.
- 2 Channels for simultaneous capture and comparison of two different signals.
- 500 MSa/s Sample Rate for an accurate and detailed representation of waveforms.
- Large 7-Inch Display ensures excellent readability and clear analysis of measurement results.
- 64 kpts Memory Depth allows for the recording of longer signal sequences without loss of detail.
- Versatile Trigger Options (Edge, Pulse Width, Video) for reliable isolation of the desired signal.
- Automatic Measurement Functions for fast and efficient analysis of up to 34 waveform parameters.
- USB Connectivity for easy data transfer to a PC and convenient saving of screenshots.
- EU Compliant & Safe tested according to European standards for maximum user safety in labs and workshops.
Your Reliable Partner for Precise Waveform Analysis
The UNI-T UTD2052CL+ is a digital storage oscilloscope specifically designed to meet the needs of education, ambitious hobby electronics enthusiasts, and professional field service. It combines a robust design with intuitive operation and all the essential functions you need for daily measurement tasks. Without the complexity or cost of high-end instruments, it provides reliable performance for basic electronics testing.
Perfect for Beginners, Makers, and Field Service
Thanks to its straightforward user interface and clearly arranged controls, even beginners can get started quickly. The large 7-inch color display presents waveforms sharply and in detail, making signal analysis much easier. Whether you're working on Arduino or Raspberry Pi projects, debugging circuits, or performing quick diagnostics in the field, the compact and lightweight UTD2052CL+ is the ideal companion. The zoom function allows you to magnify interesting parts of the signal to closely examine glitches or timing details.
Safety and Compliance First
Your safety is our priority. Therefore, the UNI-T UTD2052CL+ has been carefully tested and certified. It complies with all relevant EU standards, so you can count on safe and reliable operation in your lab, workshop, or educational environment. Invest in a measuring instrument that is not only precise but also safe.
A Classic for Basic Measurement Tasks
Please note that this model is a proven classic that has since been superseded by newer series. It is excellent for all basic measurements. However, if you require advanced features such as protocol decoding, a higher sample rate, or more channels, we recommend taking a look at the more modern devices in the UNI-T UPO series.
Technical Specifications
| Feature | Specification |
|---|---|
| Bandwidth | 50 MHz |
| Channels | 2 |
| Sample Rate (Real-Time) | 500 MSa/s |
| Memory Depth | 64 kpts |
| Display | 7-inch TFT LCD, WVGA (800x480) |
| Trigger Types | Edge, Pulse Width, Video |
| Math Functions | Addition, Subtraction, FFT |
| Automatic Measurements | Frequency, Period, Rise/Fall Time, Amplitude, Duty Cycle, and more. |
| Interfaces | USB Host (for data storage), USB Device (for PC connection) |
| Safety | Meets EU safety standards (CE certified) |
Frequently Asked Questions (FAQ)
What is the difference between the CL+ and CEX+ models?
The CEX+ models feature a higher sample rate (typically 1 GSa/s), which provides better waveform fidelity at higher frequencies. The CL+ models, like this one, offer an excellent price-performance ratio at 500 MSa/s for standard applications.
Does the oscilloscope support serial bus decoding (e.g., I2C, SPI)?
No, the UTD2000 series is designed for basic analog waveform measurement. For protocol decoding, we recommend the MSO/UPO series from UNI-T.
Can I save waveforms and screenshots?
Yes, the USB interface allows you to easily save waveform data and screenshots to a USB drive or a connected PC. This is ideal for documenting your measurement results.
Is the device safe for use in the EU?
Absolutely. The UTD2052CL+ is CE certified and has been tested according to the strict European directives for electrical safety and electromagnetic compatibility (EMC). You can use it with confidence in professional and private settings.
