UT18C Voltage Tester, Continuity Tester, IP65
| Quantity | Unit price |
|---|---|
| To 4 |
€37.27*
|
| To 9 |
€35.41*
|
| From 10 |
€34.29*
|
Currently not available (delivery time on request)
| Product number: | 202582 |
|---|---|
| Manufacturer number: | UT18C |
| EAN | 6935750518038 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
UT18C Voltage Tester/Continuity Tester Description
The UT18C AC/DC voltage and continuity tester is a reliable and easy-to-use tool for testing voltages in a wide range of applications. With its 12V - 690V AC/DC voltage test range, 50 to 60 Hz rotary field test range, LED indication and LCD display, two-pole and single-pole voltage test, continuity test, and polarity indication for DC voltages, the UT18C is a versatile voltage tester that can handle all your testing requirements. Additionally, the self-test function ensures proper functioning, while the battery warning provides convenience.
With its IP65 protection class rating and the switchable LED working light, the UT18C is built to withstand and function in even the most demanding environments.
The UT18C complies with all EU safety standards and has a CAT IV 600V rating.
UT18C Voltage Tester/Continuity Tester Features
- AC/DC voltage test 12 - 690 V
- Rotary field test 50 to 60 Hz
- RCD test
- LED indication and LCD display
- two-pole and single-pole voltage test (single-pole: 100 V to 690 V AC, 50 Hz to 400 Hz)
- continuity test 0 to 100 kOhm (acoustic signal + LED indicator)
- Polarity indication for DC voltages
- self-test function to ensure proper functioning
- automatic measuring range selection
- switchable LED working light
- battery warning
- Protection class: IP65
- Scope of delivery: Device, Manual
| Product number: | 202582 |
|---|---|
| Phase Rotation Test: | 57Vac～400Vac (3 phase); Frequency: 50Hz~400Hz |
| Single Lead (L2) Voltage Detection: | Operating voltage: 100V~690V; Frequency: 50Hz~400Hz |
| Continuity Test: | Resistance: 0Ω~100kΩ (+50% accuracy); Beeper and LED light indication |
| RCD Test: | Operating voltage: 230V (50Hz~400Hz) |
| Polarity detection: | Positive & Negative |
| LCD Voltage Display: | 6V~690V ±(1.5%+5) |
| LCD Frequency Display: | 40Hz~400Hz ±(3%+5) |
| Rating: | CAT IV 600V |
| Auto Power Off: | ✓ |
| Polarity: | ✓ |
| Low Battery Indication: | ✓ |
| Flashlight: | ✓ |
| Display: | ✓ |
| IP Protection Rating: | IP65 |
| Display Size: | 31mm x 20mm |
| Size: | 272mm x 85mm x 31mm |
| Weight: | 0.28kg |
| Power Supply: | 1.5V battery (R03)×2 |
| Size: | 272mm x 85mm x 31mm |
| Weight: | 0.28kg |
