UT511 Professional Insulation Resistance Tester
| Quantity | Unit price |
|---|---|
| To 4 |
€115.00*
|
| To 9 |
€109.25*
|
| To 24 |
€105.80*
|
| To 49 |
€100.63*
|
| From 50 |
€92.00*
|
Available, delivery time: 1-3 days
| Product number: | 200377 |
|---|---|
| Manufacturer number: | UT511 |
| EAN | 6935750551103 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
UT511 Insulation Resistance Tester Description
The UT511 insulation tester is a versatile and easy-to-use instrument for measuring insulation resistance, polarization index (PI) and dielectric absorption ratio (DAR). It features a large 9999 counts display with 30-segment analog bar graph, comparison, upper and lower limit functions, and a continuous measurement mode. The UT511 also has a time measurement mode, auto range, and auto measure function, making it ideal for use in various applications where precise measurements are critical. Additionally, the UT511 can store up to 18 data groups, features low battery and over range indications, an auto power off function, a LCD display with backlight, and a high-voltage output alarm.
Overall the UT511 is solid choice for professionals, who are looking for a high-quality insulation resistance tester.
The UT511 complies with all EU safety standards.
UT511 Insulation Resistance Tester Features
- Insulation resistance, Polarization index (PI and Dielectric absorption ratio (DAR) measurements
- Large 9999 display with 30-segment analog bar graph
- Comparison, upper and lower limit functions
- A continuous measurement mode, time measurement mode and auto measure within 15 minutes
- 18-group data storage
- Auto current discharge and high-voltage output alarm
- Low battery and over range indications
- Auto power off function
- Backlight
- Scope of delivery: Device, 2pcs of one plug test leads to one alligator clip (black and green), 1pcs of two plugs test lead to one alligator clip (red), Manual
| Product number: | 200377 |
|---|---|
| AC Voltage: | 750V ±(2%+3) |
| Auto Power Off: | ✓ |
| Auto Range: | ✓ |
| Comparison Measurement: | ✓ |
| DC Voltage: | 1000V ±(2%+3) |
| Dielectric Absorption Ratio (DAR): | ✓ |
| Display Size: | 123mm x 58mm |
| High Voltage Indication: | ✓ |
| Insulation Resistance: | 100V: 0.1MΩ~500MΩ ±(3%+5); 250V: 0.5MΩ~2GΩ ±(3%+5); 500V: 1MΩ~4GΩ ±(3%+5); 1000V: 2MΩ~10GΩ ±(3%+5) |
| Low Battery Indication: | ✓ |
| Low Resistance: | 0.1Ω~999.9Ω ±(1%+3) |
| Overload Indication: | ✓ |
| Polarization Index: | ✓ |
| Power Supply: | 1.5V battery (LR14) x 8 |
| Short-circuit current: | <2mA |
| Test Voltages: | 100V~1000V 0%~10% |
| Worklight: | ✓ |
| Weight: | 1.2kg |
| Size: | 202mm x 155mm x 94mm |
| Size: | 202mm x 155mm x 94mm |
| Weight: | 1.2kg |
| Flyer: | 20181213041713788.pdf |
|---|---|
| Manual: | UT511-English-Manual.pdf |
