UTi120B Thermal Imaging Camera, 120 x 90 IR Resolution
| Quantity | Unit price |
|---|---|
| To 4 |
€301.68*
|
| To 9 |
€286.60*
|
| To 24 |
€271.51*
|
| From 25 |
€241.34*
|
Available, delivery time: 1-3 days
| Product number: | 202593 |
|---|---|
| Manufacturer number: | UTi120B |
| EAN | 6935750512609 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
UTi120B Thermal Imaging Camera Description
The UTi120B is the latest portable infrared thermal imaging camera from the well-known quality manufacturer Uni-Trend with a resolution of 120 x 90. Thanks to its compact design, the camera is perfectly suited for mobile use. The 2.8'' inch TFT-LCD display offers a display palette of 7 colors and 3 display modes (thermal, visible, blending). Thanks to the built-in flashlight, measurements can be taken easily even in dark environments. With the SD card slot, the memory can be expanded, which allows the recording of images. These can be stored and evaluated on the computer through the USB interface, with the help of software. With the installed mounting hole for a tripod, the particularly safe IP65 rating and a 2m drop-proof design, the camera can also be used in harsh environments without hesitation.
All in all, the UTi120B thermal imaging camera is a powerful device in a compact, sturdy and secure housing that perfectly meets the needs of professional users.
The UTi120B meets all EU safety standards and has an IP65 protection classification.
UTi120B Thermal Imaging Camera Features
- High quality workmanship
- 4" TFT LCD screen (320×240 pixels)
- IR resolution: 120×90
- Temperature measurement range: -10℃ to 400℃ / 14℉ to 752 ℉
- Automatic alarm for high/low temperature
- Hotspot detection (high/low)
- Image recording and storage in the device
- Color palettes: 7
- 3 display modes (thermal, visible, blending)
- Micro SD card slot
- USB interface
- Analysis on PC possible thanks to included software
- Rechargeable Li-Ion battery pack
- 1/4" tripod mounting hole
- 2m drop resistant
- IP65 protection classified
- Included in delivery: UTi120B thermal imaging camera, micro SD card, USB cable type-C, manual
| Product number: | 202593 |
|---|---|
| Alarm: | ✓ |
| Auto tracking for Lo/Hi temperature: | ✓ |
| Communication Interface: | USB Type-C |
| Digital Camera: | 648 x 488 pixels |
| Emissivity: | Adjustable (0.01-1) |
| Field Of View: | 51°x38° |
| Focus: | Focus free |
| Framerate: | 25Hz |
| Image Model: | Thermal, visible, blending |
| IR Resolution: | 120x90 pixels |
| LED: | ✓ |
| Palettes: | 7 |
| PC Software: | Analysis, Real-time display |
| Protection: | IP65/2m |
| ROI: | ✓ |
| Weight: | 0.91kg |
| Size: | 236mm x 75.5mm x 86mm |
| Size: | 236mm x 75.5mm x 86mm |
| Weight: | 0.91kg |
