ZD-939D ESD hot air station 320W 160-480°C 24L/min ESD-safe
| Product number: | 601109 |
|---|---|
| Manufacturer number: | ZD-939D ESD |
| EAN | 4260766895845 |
Are you a reseller, need a large quantity or have a price target?
Apply for a reseller / high volume account to get access to our wholesale conditions. You can also contact our sales team at any time via info@schwick.de or +49 2191 598 280
ZD-939D ESD hot air station – high-quality station for a wide range of applications
Product overview
The ZD-939D ESD hot air station from Zhongdi combines high performance with fast heating times. With 320 W of power and a robust design, it is the ideal choice for electronics engineers and DIY enthusiasts who expect precise results.
Precise temperature and air flow control
The temperature range from 160 °C to 480 °C allows for a wide range of applications, from gentle heating to demanding hot air work. The digital display shows the temperature and air flow volume at a glance.
A bar graph visualizes the set fan power, while the push-button control allows easy adjustment of temperature and air flow. The display can be set to °C or °F.p>
Intelligent functions
The integrated sleep function switches the station to energy-saving mode as soon as the hot air handle is placed in the holder. When the handle is lifted, the station automatically returns to normal operation. p>
Safety and ESD protection
As an ESD-safe station, it protects sensitive components from electrostatic discharge. High-quality diaphragm pumps ensure a constant air flow of up to 24 L/min without fluctuations.
Design and ease of use
The modern design of the station combines clearly arranged controls with a flexible cable on the hot air piston, which offers maximum freedom of movement. The push buttons and large display ensure intuitive operation.
Scope of delivery and areas of application
The scope of delivery includes the hot air piston holder, four interchangeable air flow nozzles, and a pick-up tool. Thanks to its flexible control, the station is suitable for repairs, manufacturing, and prototype construction.
ZD-939D ESD hot air station – Technical data and features
- Power: 320W
- Temperature range: 160-480°C
- Max. air flow: 24L/min
- With sleep/energy-saving function
- ESD-safe
- Fast heating time
- Large digital display with dual LED display
- Scope of delivery: Station, hot air piston, hot air piston holder, 4 hot air nozzles, mounting tool, power cable, instructions
